R-807 7.1 Ch Network AV Receiver
Sherwood R-807 7.1 Ch Network AV Receiver. Includes WiFi Direct Streaming, 4K, HD Audio Decoding, Dolby TrueHD and Dolby Digital Plus.
R-807 7.1 Ch Network AV Receiver
- HD Audio Decoding
- Dolby TrueHD/Dolby Digital Plus
- DTS-HD (Master Audio / High Resolution Audio)
- Legacy Audio Decoding
- Dolby Digital / Dolby Digital EX / Dolby Prologic llz
- DTS-ES (Discrete / Matrix)
- DTS 96/24, DTS Neo 6 (Cinema / Music)
- 5 In / 1 Out HDMI Repeater (3D / ARC / CEC)
- World 1st WiFi-Direct Built-in AV Receiver
- 4K Passthrough (For Ultra HD Video Support)
- World 1st WiFi-Direct Built-in AV Receiver
- Free Sherwood Application for both iOS & Android
- Internet Radio / Media Server (via LAN)
- Front USB Input : MP3 / WAV / WMA / AAC
- Graphic OSD
- One Touch Automatic Speaker Setup
- 192kHz/24bit D/A Converter (All Channel)
- 2 Zone Multi Room / Multi Source for Audio
Amplifier
- 100W x 7ch (1kHz, THD 1%) @6Ω / One Channel Driven
- 75W x 2ch (20Hz~20kHz, THD 0.1%) @ 6Ω / Stereo Mode
- Heavy Duty Speaker Binding Posts
- Assignable 2 Channel Power Amp:
- Surround Back L/R
- Room2 / Bi-Amp
General
- Colour Coded Terminals
- 6.5mm Headphone Jack
- Remote Controller
- Color Availability : Black
Amplifier
- Power Output - Stereo: 75W x 2ch (20Hz~20kHz, THD 0.1%) @6Ω / Stereo Mode
- Power Output - Surround: 100W x 7ch (1kHz, THD 1%) @6Ω / One Channel Driven
- Input Sensitivity/Impedance: 200 mV/47k ohms
- S/N Ratio: 95dB
- Frequency Response: 10-100kHz +/- 3dB
- High Instantaneous-current Capability (HCC): +/- 25 amps
FM Tuner
- Frequency Range: 87.5 - 108.0MHz
- RDS Function:
- RDS, PTY, TP Search
- PS, RT, CT
- Usable Sensitivity (IHF): 1.3uV 13.2dBf
- S/N Ratio (Mono / Stereo): 65dB / 62dB
- THD (Mono / Stereo): 0.2% / 0.3%
- Stereo Separation: 1kHz, 35dB
- Image Rejection: 80dB
- IF Rejection: 80dB
AM Tuner
- Frequency Range: 522 - 1611kHz
- Usable Sensitivity: 500uV
- S/N Ratio: 45dB
- IF Rejection: 30dB
- Selectivity (+/- 10kHz): 30dB
Video
- Video Format: NTSC / PAL
- Input Level / Impedance: 1Vp-p / 75 Ohms
- Output Level / Impedance: 1Vp-p / 75 Ohms
- Frequency Response: (Composite Video) 10Hz - 8MHz ( -3dB)
- HDMI: 1.4a with 4K Passthrough / 3D / ARC / CEC / Deep Colour
General
- Power Consumption: < 0.5W (Standby), 280W Maximum
- Dimensions: 435mm W x 141mm H x 379mm D
- Weight: 10.4kg
