RD-705i 7.1 Ch Network AV Receiver
Sherwood RD-705i 7.1 Channel Network AV Receiver. Features HD Audio Decoding for Blu-Ray, DTS-HD (Master Audio/High Resolution Audio), Dolby TrueHD and Dolby Digital Plus.
RD-705i 7.1 Ch Network AV Receiver
- 100W x 2 in Stereo Mode
- 100W x 5 in Surround Mode
- DTS-HD Master Audio / High Resolution Audio
- Dolby TrueHD, Dolby Digital Plus
- DTS-ES, DTS 96/24, DTS Neo 6
- Dolby Digital EX, Dolby Prologic IIz
- 192kHz / 24 Bit D/A Converter (all channels)
- WiFi Dongle
- USB Host
- 192kHz / 24 Bit D/A Converter (All Channels)
- Internet Radio and Audio Streaming
- DLNA / UPnP Stack to Play Music from PC to Multiple Device
- Multi Channel PCM Decoding
- 7 DSP modes (Theater, Hall, Stadium, Room, Panorama, Classic, Multi CH Stereo)
- One Touch Automatic Speaker Setup
- Room Acoustic Calibration with EQ
- HDMI v1.4 with 3D, ARC – 3 in / 1 Out (Repeater)
- 2 Zone Multi Room/Source for Audio
Amplifier
- Power Output - Stereo: 80W x 2 (40Hz ~ 20kHz, THD 0.1%) @ 6 Ohm / Stereo Mode
- Power Output - Surround: 100W x 7 (1kHz, THD 1.0%) @ 6 Ohms, One Channel Driven
- THD: 0.04%
- Input Sensitivity/Impedance: 250mv Line (CD, Tape, Video @ 47k Ohm)
- S/N Ratio: 95dB
- Tone Controls:
- Bass (100Hz) /- 10dB
- Treble (100Hz) /- 10dB
- Frequency Response: Line (CD, Tape, Video) 10-100kHz
FM Tuner
- Frequency Range: 87.5-108.0MHz
- RDS Function:
- RDS, PTY, TP Search
- PS, RT, CT
- Usable Sensitivity (Mono): 12.8dBf
- 46dB Quieting Sensitivity:
- Mono 20.2dBf
- Stereo 45.3dBf
- S/N Ratio (65dBf):
- Mono 55dB
- Stereo 50dB
- THD (65dBf, 1kHz):
- Mono 0.4%
- Stereo 0.4%
- Frequency Response: 30Hz-14kHz, /- 3.0dB
- Stereo Separation: 1kHz, 35dB
- AM Suppression Ratio: 45dBf, 40dB
- Image Rejection Ratio: 94dB
- IF Rejection Ratio: 76dB
AM Tuner
- Frequency Range: 522-1611kHz
- Usable Sensitivity: 400uV/m, 500uV
- THD: 400Hz, 30% Modulation, 0.4%
- S/N Ratio: 40dB
- Frequency Response: 54Hz-2.kHz
- Image Rejection Ratio: 36dB
- Selectivity: 29dB
Video
- Input Sensitivity: 75 Ohm, 1Vp-p
- Output Level: 75 Ohm, VCR/Monitor Out, Composite, 1Vp-p
- Frequency Response: Composite Video/S-Video, 10Hz-10MHz ( /- 2dB)
- Crosstalk: 50db (1MHz)
General
- Dimensions: 435mm W x 141mm H x 330mm D
- Weight: 9.2kg
